B4-2516 เครื่องตัดระบบดิจิตอลหน้ากว้างแท่นตัดแนวราบ    รุ่น  ---  B4-2516 Large Format Flatbed Digital Cutting Machine
  • B4-2516 เครื่องตัดระบบดิจิตอลหน้ากว้างแท่นตัดแนวราบ    รุ่น  ---  B4-2516 Large Format Flatbed Digital Cutting Machine

See larger image and other views (with zoom)

B4-2516 เครื่องตัดระบบดิจิตอลหน้ากว้างแท่นตัดแนวราบ รุ่น --- B4-2516 Large Format Flatbed Digital Cutting Machine

   |   46 Transactions

รหัสสินค้า:SIT-AMD-B4-2516

Buyer Protection

เครื่องตัดระบบดิจิตอลแท่นตัดแนวราบ    รุ่น B4 -  2516

คำอธิบาย:

เครื่องตัดระบบดิจิตอลรุ่น B4-2516 นี้สามารถสร้างรอยตัดครึ่ง, สร้างรอยเจาะเพื่อทำรอยพับ, สามารถเจาะรูและสร้างโครงรูปที่ซับซ้อนได้     ด้วยความเร็วสูงรวมถึงละเอียดแม่นยำโดยใช้แท่นสายพานลำเลียงซึ่งเครื่องตัดระบบดิจิตอล  รุ่น  B4-2516 นี้สามารถป้อนและเก็บวัสดุได้อย่างเสร็จสิ้นสมบูรณ์รวมถึงมีความรวดเร็วซึ่งเหมาะสำหรับใช้สร้างตัวอย่างที่การผลิตและใช้สำหรับการผลิตป้ายโฆษณาและรูปภาพระยะสั้น         รวมถึงใช้สำหรับมวลการผลิตในจำนวนมาก, ใช้ทำกล่องบรรุจุภัณฑ์ใช้สำหรับอุตสหกรรมยานยนต์และอุตสาหกรรมประเก็นและอื่นๆอีกมากมาย



 คุณสมบัติ:

•  ใช้หัวมีดตัดที่มีประสิทธิภาพสูง

•  ระบบตำแหน่งกล้องส่องอัตโนมัติซึ่งมีความละเอียดแม่นยำสูง   (  อุปกรณ์เสริม   )

•  ระบบแท่นสายพานลำเลียงอย่างต่อเนื่อง  (  อุปกรณ์เสริม   )

•  แท่นตัดอลูมิเนียมที่มีความแข็งแรงทนทาน

•  อุปกรณ์มีความปลอดภัย

•   อุปกรณ์เครื่องมือตัด:     เครื่องมือหมุน,  อุปกรณ์หมุน, มีดเจาะสร้างรอยพับ, ใบมีดทรงตัว V ,ใบมีดหมุนวงล้อ, เครื่องมือสร้างชั้นร่อง,  เครื่องมือมีดตัดโฟม, เครื่องมือตัดวงล้อและเครื่องมืออื่นๆอีกมากมาย





Standard CCD system, oscillating knife, drag knife
Optional creasing wheel / V-cut / kiss cut, Choose one of three



Digital Contour Cutting Machine 2516

Description:
B4-2516 Flatbed digital cutting system can realize through cutting, half cutting, creasing, milling, punching and nesting with high speed and high precision. With conveyor table, B4-2516 can complete the material feeding and collecting with fast speed. It is quite suitable for sample making, short-run and mass production in Sign & Graphic, Packaging, Automotive, Gasket industries.


Features:
• Efficient cutting heads
• Precise automatic camera positioning system (optional)
• Continuous conveyor table system (optional)
• Aviation aluminum table
• Safety device
• Cutting Tools: Oscillating tool, Rotary tool, Kiss-cut, V-cut, Creasing wheel tool, Router tool, Foam cut tool, Wheel cut tool etc.

Details  /   รายละเอียด  :

Oscillating Knife
ใบมีด กวัดแกว่ง

The EOT is ideally suited for cutting softer,medium-density materials. The high oscillating frequency makes it possible to cut at high processing speeds for greater throughput. To accommodate different substrates and levels of detail, Ameida offers a wide range of both flat and pointed oscillating blades.
ใบมีดเครื่องตัดชนิดนี้ เหมาะสำหรับ ใช้ประมวลผลการตัด วัสดุที่มีความหนาแน่น ระดับปานกลาง และอ่อน โดยการกวัดแกว่งที่แรง และมีความถี่นั้น สามารถตัดวัสดุได้ ด้วยความเร็วสูง ช่วยทำให้สามารถ ส่งผ่านการตัดไปยั้ง รายละเอียดของพื้นผิว และระดับชั้นของวัสดุ ที่มีความแตกต่างกันได้ อย่างยอดเยี่ยม ซึ่งรูปแบบใบมีด ที่ใช้กวัดแกว่งในการตัดนั้น มีทั้งใบมีดแบน และใบมีดปลายแหลม

V-cut
เครื่องตัด ใบมืดตัว "V"
The V-Cut Tool is the perfect tool for producing complex structural designs from foamcore or sandwich board materiails. The well thought-out design of this tool makes for quick tool changes and easy, precise setting of the various cutting angles. The tool can be set for cutting at different angles
เครื่องมือมีดตัด รูปทรงตัว" V" หรือ V-Cut นี้ เป็นเครื่องมือที่สมบูรณ์แบบ สำหรับใช้ประมวลผลการผลิต ที่มีการออกแบบโครงสร้าง อย่างซับซ้อน ได้เป็นอย่างดี ตั้งแต่วัสดุโฟม ไปจนกระดาษรวงผึ้ง โดยการออกแบบ ที่ดีของเครื่องมือนี้ ช่วยทำให้การเปลี่ยนอุปกรณ์ สามารถทำได้ อย่างรวดเร็ว และง่ายดายเป็นอย่างยิ่ง อีกทั้งอุปกรณ์นี้ ยังสามารถตั้งค่า สำหรัการตัดมุม ที่หลากลาย ได้อย่างมากมายอีกด้วย
Drag Knife
เครื่องมือ ใบมีดลากตัด

The Universal Cutting Tool is perfect for through-cutting materials with thicknesses up to approx. 5mm/3/16". The use of drag knives allows for maximumprocessing speeds,and compared to motor-driven tools, the UCT is very inexpensive to purchase and maintain. A spring-loaded glide,shoe permits cutting very fine details. Optionally, a fixed glide shoe can be used for cutting at set depths.
เครื่องมืดตัด รูปแบบสากลนี้ เหมาะสำหรับใช้ตัดผ่าน วัสดุที่มีความหนาได้ ประมาณ ไม่เกิน 5 ม.ม. / 3/16 นิ้ว โดยวิธีการลากใบมีดนั้น ช่วยให้สามารถประมวลผล ได้อย่างรวดเร็วสูงสุด และเมื่อเทียบกับ เครื่องมือ ที่ขับเคลื่อนด้วยมอเตอร์อื่นๆ เครื่องมือมีดตัด รุ่น AMD-UCT นี้ มีราคาที่ไม่แพง เป็นอย่างมาก สำหรับที่จะซื้อมาใช้งาน และจัดเก็บรักษา โดยสปริงค์โหลดเลื่อนนั้น สามารถใช้ตัดรายละเอียด ด้านล่างวัสดุ ได้อย่างยอดเยี่ยม ซึ่งคุณสามารถเลือกได้ โดยปลายอุปกรณ์นั้น สามารถใช้ตัด และตั้งค่าระดับความลึกได้

Kiss Cut
เครื่องมือ ใบมีดแตะสัมผัส
For vinyl-cutting applications and especially kiss-cutting,perfect accuracy in the cutting depth is essential. The variable pressure of the kiss-cut tool permits precise cutting of foils without damageing the liner material. Besides commonly used vinyl and other films up to 3mm(1/8")thick, this tool can also be used for cutting thin paper and card stock. a fixed glide shoe comes with the tool and is used for through-cutting cardboard and Diamond Grade vinyl.
ใบมีด เครื่องมือตัดชนิดนี้ เหมาะสำหรับใช้ตัดไวนิล และโดยเฉพาะอย่างยิ่ง ใบมีด Kiss Cut หรือใบมีด ตัดแตะสัมผัสนี้ มีความละเอียดแม่นยำ เป็นอย่างยิ่ง ในการตัดระดับความลึก ได้อย่างสมบูรณ์ ซึ่งเป็นสิ่งที่สำคัญเป็นอย่างยิ่ง โดยตัวแปรแรงดัน ของเครื่องมือมีดตัด Kiss Cut หรือใบมีด ตัดแตะสัมผัสนี้ ช่วยให้สามารถตัดชิ้นงาน ได้อย่างละเอียดแม่นยำ อีกทั้งยังไม่สร้างความเสียหาย ที่ด้านในวัสดุอีกด้วย ซึ่งโดยทั่วไปแล้ว ใช้สำหรับตัดไวนิล และแผ่นฟิล์มอื่น ๆ ที่มีความหนา ไม่เกิน 3 ม.ม. (1/8 นิ้ว ) รวมถึงเครื่องมือ มีดตัดนี้ ยังสามารถใช้ตัดกระดาษ และแผ่นการ์ดบาง ๆ ได้อีกด้วย โดยฐานติดตั้ง มาพร้อม เครื่องมือ ซึ่งใช้สำหรับตัดผ่าน กระดาษลัง และไวนิล เกรดเพชร ได้อย่างยอดเยี่ยม
Crease Wheels
เครื่องมือ ใบมีดวงล้อ สร้างรอยพับ
The CTT is perfect for prcessing single-wall corrugated cardboard. the tool produces high-quality creases both with and against the corrugation without tearing or cracking the top layer, the crease wheels simply snap into the holder, making them very to insert and replace.
เครื่องมือตัดรุ่น AMD CTT นี้ เหมาะสำหรับประมวลผล กระดาษลูกฟูก ด้านเดียว โดยเป็นเครื่องมือ ที่ใช้สร้างทั้งรอยพับ ที่มีคุณภาพสูง ทั้งปกป้องร่อง ของพื้นผิวลูกฟูก ไม่ให้เกิดการฉีกขาด และป้องกันชั้นด้านบน ของพื้นผิววัสดุ ไม่ให้เกิดรอยแยกแตก โดยใช้ล้อพับ ในการประมวลผล เพื่อให้ง่ายสำหรับการประกอบ โครงสร้าง แม่แบบ
CCD System
ระบบกล้อง CCD
Through the identification of cameras, as well as the positionging of the function of the CCD,and auxiliary cutting machine. Perfect meet customer requirements. Production of high quality products.
ใช้กล้องส่องผ่าน เพื่อระบุตำแหน่ง เช่นเดียวกันกับการวาง ตำแหน่งกล้อง CCD ซึ่งเป็นอุปกรณ์เสริม จึงสามารถตอบสนอง ความต้องการของลูกค้า ได้อย่างสมบูรณ์แบบ เพื่อการผลิตสินค้า ที่มีคุณภาพสูง
Milling tool เครื่องมือมิลลิ่ง AT the heart of RZ is a 300w router spindle which operates at up to 60000rpm, depending on material and application. In combination with the 3mm bits Ameida offers, this routing/engraving tool delivers solid performance in a wide range of applications. Aside from processing softer materials, the tool can also process more chllenging substrates in multiple passes.
In a few quick steps, the RZ can be converted from routing to engraving. In Engraving mode, the height of the tool relative to the material surface can be precisely adjusted with a micrometer screw.this ensures precision engraving,with consistent line widths and depths.
The airflow from the dust-extraction effectively cools both the router bit and the spindle,which significantly increases their longevity.

หัวใจหลักของเครื่องมือตัด รุ่น AMD - RZ นี้ คือใช้แกนหมุน พลังงาน 300 วัตต์ซึ่งทำงานที่ความเร็ว 60000 รอบ / นาที ทั้งนี้ขึ้นอยู่กับวัสดุ และการนำไปใช้งาน โดยการทำงาน ของเครื่องมือ คือการกำหนดเส้นทาง สำหรับการแกะสลัก โดยให้ประสิทธิภาพที่มั่นคง ในการนำไปใช้งาน ได้อย่างหลากหลาย ตั้งแต่ใช้ประมวลผล วัสดุที่มีความอ่อน ซึ่งเครื่องมือนี้ ยังสามารถประมวลผลพื้นผิววัสดุ ที่ไม่เรียบได้ อย่างหลากหลาย และรวดเร็ว ในไม่กี่ขั้นตอน โดยเครื่องตัด รุ่น AMD - RZนี้ ยังสามารถแปลง จากเส้นทางการตัด ไปยังการแกะสลักได้ ในโหมดแกะสลัก โดยความสูง ของเครื่องมือนั้น มีความสัมพันธ์ กับพื้นผิวของวัสดุอย่างสอดคล้อง และอุปกรณ์เครื่องมือนั้น สามารถปรับได้ อย่างละเอียดแม่นยำ โดยน็อตสกรู จึงสามารถมั่นใจได้ ในกระบวนการแกะสลัก ที่มีความละเอียดแม่นยำสูง โดยให้เส้นความกว้าง และเส้นความลึก ของการแกะสลักนั้น ที่มีความสม่ำเสมอ อย่างยอดเยี่ยม อีกทั้งอากาศที่ไหลเวียน ของเครื่องดูดฝุ่นนั้น มีประสิทธิภาพ ช่วยลดอุณหภูมิ ของทั้งส่วน ของแกนหมุน และเครื่องมือหมุน ได้อย่างยอดเยี่ยม ซึ่งช่วยยืดอายุการใช้งานได้ อย่างยาวนาน อย่างมีนัยสำคัญ


Application:
